Zoll AED 3 fully automatic defibrillator

When every second counts. The AED 3 is a fully automatic external defibrillator for treating sudden cardiac death in adults and children. Its audio and text instructions guide every first responder safely through reanimation. Thanks to its Real CPR Help technology, the user gets feedback in real time about whether everything is done correctly. An integrated metronome helps keep up the rhythm.

Product details

• Fully automatic system
• Real CPR Help technology: realistic usage images on color display, CPR cycle timer, large color-coded bar display for showing depth of compressions
• RapidShock analysis
• Integrated metronome
• CPR-Uni-padz
• Cloud connection for automatic transfer of AED readiness
• Additional child mode
• Measurements (H x W x D): 12.7 cm x 23.6 cm x 24.7 cm
• Weight: 2.5 kg (with batteries)
• Incl. multimedia briefing
• Available in different language versions

Special features of the AED 3 fully automatic device

With the AED 3 you are getting an AED that is prepared for every emergency situation: It has a status display that allows you to determine whether the device has passed the last self-test and is therefore ready for use. The device runs these self-tests every day or every 7 days depending on the setting. Once a month, it also runs a self-test at full energy of 200 J. During the self-test, the AED checks the following 3 functions:

• Capacity
• Status and expiry date of the battery
• Connection and expiry date of electrodes
• ECG and charging/discharging electronics
• Microprocessor hardware and software
• CPR electronics
• Pads sensor
• Audio electronics

The AED 3 has 2 operating modes: Firstly, there is the AED management mode with which all configuration settings can be changed using the symbols on the touchscreen. Additionally, clinical archives, device history data, and configuration data can be uploaded via this mode. The other mode is the rescue mode which shows graphics on the screen that, together with audio prompts, guide the first responder through the steps of reanimation.

Another special feature of AED 3 is the child mode which employs energy settings configured for children. This mode can be activated by either using the ZOLL HLW-Uni-padz defibrillator electrodes and pressing the child button, or by directly using suitable child electrodes like Pedi-padz II.

Real CPR Help ensures that the AED 3 can offer information about the correctness of frequency and compression depth. Via a sensor on the HLW-Uni-padz, this data can be measured and evaluated. Depending on the measured depth of the cardiac massage, the AED plays audio prompts: Is the massage depth e. g. under 5 cm, it plays the prompt “Push harder”. If the minimum depth is then adhered to or reached, it plays “Good compressions”.

Technical data

• Impulse: ZOLL rectilinear biphasic
• Hold time of defibrillator charge: 3 seconds before automatic shock
• Energy settings: adults 120 J, 150 J, 200J, and children 50 J, 70 J, and 85 J
• Charging time: < 10 seconds (new battery)
• Pre-shock pause: < 8 seconds (new battery)
• Electrodes: ZOLL CPR Uni-Padz
• Self-test: every day or every 7 days; monthly test with full energy (200 J)
• Extent of automatic self-tests: capacity, status, and expiry date of the battery, connection and expiry date of the electrodes, ECG and charging/discharging electronics, microprocessor hardware and software, CPR electronics and pads sensor, audio electronics
• Shockable rhythms: ventricular fibrillation (VF) with average amplitudes of > 100 microvolts as well as ventricular broad complex tachycardia with frequencies of > 150 beats/min for adults or > 200 beats for children
• Measuring range of patient impedance: 10 - 300 Ohm
• Display format: high-resolution LCD display with capacitive touch panel
• Size of display: 5.39 cm x 9.5 cm
• Data recording & storage: 1 or 2 clinical results of 120 minutes in total, customizable by the user. Includes ECG, impedance measurements, device prompts, and CPR data
• Power supply: battery
• Wi-fi: 802.11 a/b/g/n
• Connection: USB 2.0
• Device classification: class II

Package contents

• 1 AED 3 fully automatic system in selected language
• 1 set of batteries
• 1 pack of CPR Uni-Padz
• 1 documentation package

According to MPBetriebV, a mandatory briefing is needed for AEDs and defibrillators if you're based in Germany. A multimedia briefing is included in the price. Optionally, a personal live briefing for initial operation (on-site or via livestream) can be booked.
