B. Braun Perfusor compact plus syringe pump

B. Braun’s Perfusor compactplus syringe pump is a robust pump for modern infusion therapy. The guided navigation with pictograms on the large color display ensures error-free operation and shortens training time. The portable device has a long runtime thanks to its powerful lithium-ion battery, making it suitable for both clinical and emergency medical services. The Perfusor compact plus can operate with a variety of syringe types and sizes ranging from 2 to 60 ml.

Product details

• Infusion syringe pump with semi-automatic drive
• Three different bolus deliveries:
  • Manual bolus
  • Bolus with volume preselection
  • Bolus with volume and time preselection
• Guided syringe insertion with graphically supported menu navigation
• With integrated drug database with up to 3,000 drugs and 15 drug categories
• Usable as a single pump or up to three compact plus pumps stacked via dovetail connection
• Also usable in the compact plus system
• Compact device with carrying handle
• Meets the requirements of EN 1789 and DIN EN 60601-1-12 standards for emergency medical service use
• Dimensions: 290 x 98 x 220 mm
• Weight: approx. 2.3 kg

Technical details

• Approved single-use items:
  • B. Braun Original Perfusor syringes, B. Braun Omnifix
  • BD, Terumo, Injectomat syringes
  • Syringe sizes: 2/3, 5, 10, 20, 30, 50/60 ml
• Display:
• 2.4" TFT color display
• 240 x 320 pixels
• 262K colors
• 80° viewing angle
• Rate range: 0.01–999.9 ml/h (with 50/60 ml syringe)
• Bolus delivery: delivery rate 1–1,800 ml/h
• Delivery rate accuracy: ± 2% in accordance with IEC/EN 60601-2-24
• Power supply: Li-ion battery
• Runtime: approx. 10 hours at 5 ml/h with 50 ml syringe
• Charging time: approx. 3 hours
• Protection class: IP34 (drip-proof from all directions)

Package contents

• 1 B. Braun Perfusor compact plus syringe pump
• Instruction manual
