SCHILLER FRED easyport plus FIRST defibrillator

Measuring only 14 x 15 cm, the SCHILLER FRED easyport plus defibrillator is a particularly compact and powerful pocket-sized AED that fits into any emergency kit. The semi-automatic FIRST model has been specifically designed for first responders with no prior training. FRED easyport plus assists with life-saving measures by providing detailed illustrations on the color display, CPR feedback, and clear voice instructions. The automatic electrode detection and child button for pediatric mode ensure rapid readiness in an emergency. The option for data transfer via Bluetooth and USB allows easy access to stored events.

Product details

• Semi-automatic AED with intuitive 1-2-3 interface: power on, follow instructions, deliver shock
• Suitable for all first responders
• High-resolution LCD color display with instructions and ECG curve (configurable)
• Automatic screen brightness adjustment – always perfectly visible
• Child button for reduced shock energy when using adult electrodes
• Automatic electrode detection: defibrillation energy automatically matches connected adult or pediatric electrodes
• Multipulse Biowave: biphasic defibrillation impulse for high efficiency and safety at very low energy levels
• Voice instructions with adjustable volume
• Extremely short shock recovery time for fast readiness
• Made in Switzerland
• Manufacturer’s warranty: 2 years
• Incl. primary battery (non-rechargeable) and carrying case

Package contents

• 1 SCHILLER FRED easyport plus FIRST defibrillator
• 1 disposable battery
• 1 pair of SCHILLER pre-connected RFID electrodes for adults
• 1 protective carrying case
• 1 user manual

AEDs and defibrillators require mandatory instruction in Germany in accordance with regulation MPBetreibV unless an identical model from the same manufacturer is already in use and has been instructed. Private individuals are exempt from this regulation. Instruction is not included in the price.

Technical specifications

• Shock delivery: semi-automatic
• Display: yes
• Metronome: yes
• Pacer detection: no
• ECG display: yes
• Pediatric application: pediatric electrodes, energy switch
• Waveform: BTE (Biphasic Truncated Exponential)
• Voice prompts: yes
• Memory: yes (8 Gbit)
• Storage capacity: 8 hours
• Connectivity:
• USB A 2.0 (data retrieval, software and configuration updates, Argus LifePoint feedback sensor connection)
• USB mini B 2.0 for service only
• Bluetooth 4.0
• Power supply: battery, lithium/MnO2 12 V, 16.8 Wh (non-rechargeable)
• Battery capacity (continuous operation): 4 hours 50 minutes
• Battery capacity (shocks): approx. 70–80
• Battery life (standby): 1–2 years
• Protection class: IP 44
• Operating temperature: -5 to +50 °C
• Dimensions: L 14.5 x W 15 x H 4.6 cm
• Weight (with battery): 780 g
• Display size: 3.5”, 320 x 240 px
