PARI PARI BOY Junior inhalation device

The PARI BOY Junior inhalation system is a compressor and nebulizer suitable for children for therapy of the lower respiratory tract in babies and young children. The special PARI LC SPRINT JUNIOR nebulizer provides a fine aerosol spectrum - for the most efficient therapy possible for asthma and bronchitis. The various nozzle attachments produce particularly fine aerosol droplets and can also be used for severely constricted airways. A soft, well-fitting baby mask can always be adjusted to the appropriate position by means of a freely rotatable contra-angle handpiece, thus enabling comfortable and effective inhalation therapy while sitting or lying down.

Product details

• Device set for inhalation therapy of babies and toddlers
• For inhalation of aerosols (e.g. PARI NaCl 0.9% inhalation solution)
• With variable droplet spectrum thanks to various nozzle attachments
• Incl. PARI LC SPRINT JUNIOR nebulizer with PARI PIF-Control (Peak Inspiratory Flow)
• Incl. PARI BABY mask size 2 (silicone) for infants from 1 to 3 years of age
• Application time approx. 5 to 10 minutes
• Easy handling and quick cleaning
• Dimensions of compressor: W 18.5  x H 13 x D 15 cm
• Dimensions nebulizer (without mouthpiece/mask): L 10 x W 4 x H 10 cm
• Weight compressor: approx. 1.7 kg
• Weight nebulizer (without mouthpiece/ mask): approx. 33 g
• Filling volume nebulizer: 2 - 8 ml
• The compressor is maintenance-free

Technical details

• Operating gas: air
• Nebulizer compressor flow: 3 - 6 l/min
• Operating pressure: 50 - 200 kPa
• Sound pressure level: 54 dB
• Red nozzle attachment: 3.1 - 2.6 µm MMAD (Median mass related aerodynamic diameter)
• Yellow nozzle attachment: 4.0 - 2.9 µm MMAD
• Protection class II; IP 21
• Mains voltage 220 - 240 V/ 50 Hz
• Power consumption 0.95 A

Package contents

• 1 PARI BOY Junior inhalation system consisting of
  • 1 PARI BOY Junior compressor
  • 1 PARI LC SPRINT Junior nebulizer
  • 1 PARI BABY mask (size 2)
  • 1 nozzle attachment (yellow)
  • 1 nozzle attachment (red)
  • 1 universal mouthpiece
  • 1 long connection hose
