Zoll AED Plus semi-automatic defibrillator

A device like no other. The AED plus is the first semi-automatic defibrillator which guides first responders through the entire cardiac massage audiovisually: While the display shows the depth of the compressions, the number of administered shocks, and the elapsed time, a voice guide and metronome ensure the performance of a high-quality cardiac massage. With this AED, every first responder is able to save lives.

Product details

• Semi-automatic defibrillator
• FDA approved
• Protection class IP55
• Real CPR Help technology
• LCD display for ECG, CPR control, user manual, display of elapsed time and already administered shocks
• Automatic self-test
• Integrated metronome
• Voice instruction for reanimation
• Feedback about the quality of reanimation
• Rectilinear biphasic impulse prevents the occurrence of high power peaks
• Full reanimation chain in pictogram on device surface
• Individually customizable: ECG, shock energy, voice instructions
• Integrated storage for the recording of reanimation data
• Incl. infrared interface for data transfer to a laptop or PDA
• Free software for data evaluation
• Exchangeable lithium manganese dioxide batteries
• Dust-resistant and moisture-resistant
• Measurements (H x W x D): 13.3 cm x 24.1 cm x 29.2 cm
• Weight: 3.1 kg
• Includes multimedia briefing
• Available in different language versions

The perfect support for first responders

According to the 2010 guidelines of the European Resuscitation Council (ERC), a successful defibrillation can only be administered when a high-quality cardiac massage is performed too. This high-quality massage has to have the appropriate depth and frequency. Many people are scared of not being able to fulfill these requirements and shy away from administering cardiac massages in emergency situations. With its CPR technology, the AED Plus is therefore the right choice as it offers the necessary support.

Only a good cardiac massage can restore the heart’s rhythms so that a subsequent shock could be administered. But also after an administered shock, the cardiac massage helps to supply the heart with blood and to return to its natural rhythm. A good cardiac massage is achieved when the compressions reach a depth of at least 5 - 6 cm and a frequency of at least 100 compressions/minute. In order to eliminate uncertainties about whether these requirements are met, the Real CPR Help technology of AED Plus provides feedback about whether the administered compressions are deep and frequent enough.

Via the electrode sensor of the CPR-D-padz electrode, the AED Plus recognizes chest compressions. Audiovisual information about the quality of the compressions is provided in real time. A continuously moving bar on the display shows the compression depth. In order to maintain the rhythm, the integrated metronome guides the user to the recommended frequency of at least 100/minute. The shocks are triggered via the clearly visible shock button, as soon as it is pressed according to the audio instruction.

But AED Plus not only supports the user in being an excellent first responder through its technology. Its additional equipment also supports the user in emergency situations: The one-piece CPR-D-padz electrode can not only be applied quickly and easily, it also has a first aid kit attached to it which includes further equipment for successful first aid. The device’s case lid serves as a passive support for the user and keeps the patient’s airways free.

To ensure that the AED Plus is always ready for use, the battery life is displayed with a red X. If this X is displayed, approx. 9 shocks remain and new batteries should be put in as soon as possible.

Technical details

• Protocole: semi-automatic configuration
• Impulse: ZOLL rectilinear biphasic
• Hold time of the defibrillator charge: 30 s
• Energy settings: automatic preprogrammed selection (120 J, 150 J, 200 J)
• Patient safety: all patient connections are electrically isolated
• Charging time: less than 10 seconds (with new batteries)
• Electrodes: ZOLL CPR-D-padz, Pedi-padz II, or Stat-padz II
• Self-test: Customizable self-test every 1 - 7 days. Standard setting = every 7 days. Monthly test will full energy (200 J)
• Shock rhythms: ventricular fibrillation with average amplitudes of > 100 microvolts and ventricular broad complex tachycardia with frequencies of > 150 beats/min for adults or > 200 beats/min for children
• Measuring range of patient impedance: 0 - 300 Ohm
• Display format: optional LCD display with changeable bar display
• Power supply: 10 lithium manganese dioxide batteries of type 123A
• Battery capacity: 5 years, 225 shocks, or 13 h monitoring in continuous use (fresh batteries)
• Data recording & storing: 7 h ECG and CPR data, 20 min audio recordings and ECG and CPR data
• Minimum requirement for PC for configuration and access to patient data (not compatible with Mac OS): Windows XP, Windows 7, Windows 8, Windows 10, IBM compatible PII with serial interface 16550 UART (or higher), 64 MB RAM, VGA monitor (or better), CD ROM drive, IrDA interface, 2 MB hard drive space
• Device classification: class III

Package contents

• 1 AED Plus semi-automatic system in selected language
• 1 CPR-D electrode
• 10 lithium manganese dioxide batteries
• 1 bag

According to MPBetriebV, a mandatory briefing is needed for AEDs and defibrillators if you're based in Germany. A multimedia briefing is included in the price. Optionally, a personal live briefing for initial operation (on-site or via livestream) can be booked.
