Philips HeartStart HS1 AED defibrillator

Saving lives has never been easier! The Philips HeartStart HS1 is an easy-to-use defibrillator. It is not only small and handy, but also has a voice function that will guide you through the process of treating a victim of suspected cardiac arrest. The integrated SMART pads get placed on the person’s skin and send data to the defibrillator, which then takes into account how the reanimation treatment is going. The AED can detect cardiac arrhythmias quickly and prevent cardiac death.

Product details

• Handy AED with voice commands
• Voice commands available in German, English, French, and Dutch
• Easy to use
• Daily self-test
• Biphasic waveform and heart rhythm movement
• Incl. long-life battery (4 years), carrying case, smart pads (electrodes), and “pull” sticker (in the selected language)
• Dimensions: D 7 x W 21 x H 19 cm
• Weight: 1.5 kg
• Available with different carrying bags:
• Standard case: Plenty of storage space inside the case's lid for batteries, replacement pads, and equipment, dimensions: B 24 x H 21 x D 12 cm
• Slim case: Compact size with strap for cloth scissors, plenty of space for CPR mask and gloves, dimensions: B 24 x H 21 x D 9 cm
• Available in different language

Technical specifications

• Defibrillator model: HeartStart HS1 M5066A
• Defibrillator family: HSI
• Waveform: biphasic truncated exponential waveform. Wave parameters are adjusted according to patient’s pulse
• Energy: constant final energy rating; adults: 150 Joules nominal, delivered at a load resistance of 50 ohms; infants / children: 50 Joules nominal, delivered at a load resistance of 50 ohms
• Automatic energy adjustment based on the SMART pads electrode class used
• Cycle time between shocks: normally less than 20 seconds
• Quick shock function: delivered less than 8 seconds after CPR
• Temperature: 0 to 50 °C
• Relative humidity: operating: 0 to 95 % (non-condensing)
• Height above sea level: 0 to 4,572 m
• Impact resistant (up to 1 meter fall)
• Vibration: Heartstart complies with EN 1789 Random and sine sweep specification for ambulance use and standby mode
• Type: 9 volt DC, 4.2 Ah, long-life disposable lithium manganese oxide battery (primary cell)
• Capacity: at least 200 defibrillations or 4 h operating time (EN 60601-2-4: 2003)
• Latest use date: battery is marked with the latest date on which it can be inserted into the device (no later than 3 years after manufacturing date)
• Standby: normally four years if the battery was inserted before latest use

Package contents

• 1 Philips HeartStart HS1 AED defibrillator in the selected language
• 1 carrying case in the selected version
• 1 long-life battery (pre-installed)
• 1 pair of adult SMART pads (pre-installed)
• 1 user manual

According to MPBetriebV, a mandatory briefing is needed for this product if you are based in Germany. The product includes a multimedia briefing.
